Foot-Stretcher Angle in Rowing Shells (Part 1)

Tom, my wife and me share a double. Our food stretcher height set up is very different. I tent to have it at the highest position to have an optimal foot force. Am I mistaken? – Ronald

Rowperfect has posted plenty of suggestions about the perfect rigging for people of different heights. The right set up of the foot-stretcher height is a very sensitive point, also depending on individual preferences.There are wide discussions about the foot-stretcher its right position. Even the design is under question.

We know that Biorow  has recently investigated these issues, as well. Also has worked on this topic already in 2016 (The Influence of Foot-Stretcher Height on Rowing Technique and Performance).

In both researches, the scientists modified foot-stretcher heights and examined their instantaneous effect on foot forces and rowing technique. Both came to similar conclusions. Still, their work was based on the stretcher positions on RP3 Ergometers.

Increased Foot-Stretcher height

Foot-Stretcher: High Position

Ron, you might have assumed, that raising your foot-stretcher height would increase the horizontal component of foot force and you might get a better hold on the oars.

Kleshnev and Buckeridge equiped their rowers with motion sensors. Biorow used their own device which consists of four load cells measuring only the horizontal force component at the toes-heels/ left-right foot. According to their experience, the results can be transmitted to the water. The Buckeridge  study measured ankle, knee, hip, and lumbar–pelvic kinematics.



Lower Your Foot-Stretcher

Foot-Stretcher: Low Position

We assumed, raising the height of foot-stretchers on a rowing ergometer theoretically alters the orientation of the resultant force vector in favour of the horizontal component. The opposite is the truth. Raising foot-stretcher height did not increase the horizontal component of foot force. “The reduced ability to anteriorly rotate the pelvis at the front of the stroke may be a key obstacle in gaining benefits from raised foot-stretcher heights.”

Key Results on Stretcher Force

Key resultant effects of increased foot-stretcher heights included progressive reductions in horizontal foot force, stroke length, and pelvis range of motion. Raising foot-stretcher height did not increase the horizontal component of foot force as speculated Kleshnev shows that the main rowing indicators were better when lowering the stretcher position. ” The stroke length and legs drive were longer by 1.7% and 3.0%, average handle force and work per stroke were higher by 0.6% and 2.4%.”

Stretcher Height Results, Credit: Biorow

Both study shows that small changes in athlete set-up can influence ergometer rowing technique. The results of the studies indicate that lower stretcher position could be beneficial for rowing power and technique. The data can probably be applied to the foot-stretchers in the boat. So when in doubt, take the lower position and try to feel the difference.



Good Stroke Length: What Is the Right Position?

We would recommend to put the shoes as low as they can go – before the heel touches the boat bottom. We feel that we get a better compaction at the catch. Off course all depends on your shin length. Longer shins need even lower positions. FISA / World rowing suggests in BASIC RIGGING that a good position for the height of the foot stretcher should be between 15cm to 18cm. Most boats give you options between 12 and 23 cm. Since I am a masters rower, my flexibility is not as good as years ago. So I would use a 18cm height. I feel that I get a good length and do not “dip”  into a low position during catch. My wife, she is 1.72 cm, uses a stretcher high of 15 cm. Ron, that might explain the difference between you and your wife.

Let us know your experience with the stretcher. Where is your preferred position? Are you facing slide bites? Read our blog.

On Thursday we will publish part 2 on our discussion on the optimal foot-stretcher height.

One thought on “Foot-Stretcher Angle in Rowing Shells (Part 1)

  1. Albert Willem Knop says:

    A clue to find the right height is to check whether you are able to get your shins vertical at the catch. When you are not very flexible it is difficult to get your shins vertical when the stretcher is higher. Lowering the stretcher makes it a bit easier to move all the way forward and get optimal length at the catch.
